Using the Screen

Front Screen

Once the camera is turned on, the front screen will display the following information:


Camera Status Description
Previewing Battery, storage capacity, shooting specifications, current shooting mode.
Shooting Shooting status, i.e., paused, pre-recording, countdown, etc.
Other Saving footage, connecting to app, firmware update, etc.

Flip Touchscreen

The touchscreen's main display shows the current camera shooting mode.
The menu bar shows battery level, storage capacity, and current shooting parameters.
By swiping or tapping the screen, you can achieve the following:

Gesture Description
image Tap the screen
Hide/show information on the touchscreen.
image Swipe left and right in the center
Switch shooting mode.
image Swipe from the right
Enter the shooting parameter settings.
image Swipe up from the bottom
Enter the shooting parameter settings.
image Swipe from the left
Enter the album page.
image Swipe down from the top
Enter the camera settings.

Shortcut Menu


  1. Storage: Shows the remaining number of photos or the length of video footage that can be stored on the microSD card.
  2. Battery Status: Current battery level of Insta360 Ace Pro 2.
  3. Shooting Mode: Click the icon and swipe to select a different shooting mode.
  4. Shooting Specifications: See the current shooting mode settings.
  5. Clarity Zoom: Click the icon or double-tap the screen to zoom in or out 1x or 2x without compromising image quality.
  6. Field of View: Change the Field of View.

Shooting Mode

Click the icon and swipe or swipe left and right in the center of the screen to select a different shooting mode.

Shooting Mode Description
Video Record a video with FlowState Stabilization automatically applied. Active HDR is available up to 4K60fps.
PureVideo PureVideo improves image quality in low light environments.
FreeFrame Video Apply FlowState Stabilization and Horizon Lock with adjustable aspect ratio in post via the app or Studio. Active HDR is available up to 4K60fps.
TimeShift TimeShift video can be used while moving to create a hyperlapse effect.
Timelapse Suitable for shooting static timelapse videos.
Dashcam Record continuously and save footage up to a specified amount of storage. Active HDR is available up to 4K30fps.
Loop Recording Record continuously and save only the last fixed-length segment. Active HDR is available up to 4K60fps.
Slow Motion Shoot Slow Motion video with a high frame rate.
Starlapse Shoot and store multiple photos and automatically combine Starlapse effects.
Burst Photo Take multiple photos in a short space of time.
Interval The camera automatically takes continuous photos at a specific time interval.
Photo Take a single photo.

Shortcut Menu

Swipe down on the touchscreen to view the camera settings. image Insta360

  1. QuickCapture: Turn on/off. Once enabled, press the Shutter Button when the camera is powered off to turn it on and start recording.
  2. Rotation Lock: Turn on/off.
  3. Gesture Control: Turn on/off.
  4. AI Highlights Assistant: Turn on/off. The camera finds the best moments from a single video and shows you the highlights to review. Merge them into one video or save each of them as new files. View them on the Album page.
  5. Pre-Recording: Turn on/off. Save up to 120 seconds of footage before you press the Shutter Button.
  6. Endurance Mode: Turn on/off. Acts as a low-power mode to prolong battery life. Some features and specifications are not available in Endurance Mode, such as Gesture and Voice Control.
  7. Underwater Mode: Turn on/off. Optimizes stabilization and corrects distortion underwater, delivering more realistic and natural footage.
  8. Lock Screen: Tap to lock the screen. Swipe up on the touchscreen to unlock.
  9. Grid: Turn on/off.
  10. Voice Control: Turn on/off.
  11. Audio Modes: Choose between three audio modes: Wind Reduction, Voice Enhancement and Stereo. You can select the most suitable audio mode according to the scenario.
  12. Adjust Brightness: Slide the bar to adjust the screen brightness.
  13. Timed Capture: Use the Timed Capture function.
  14. Bluetooth Remote: Search for and connect a Bluetooth remote.
  15. Bluetooth Headphones: Search for and connect Bluetooth headphones and headsets.
  16. Settings: See camera settings, such as speaker volume, turn the Indicator Light on/off, customize the Power Button, etc.

Shooting Specification Settings

Swipe up from the bottom of the touchscreen to view shooting specification settings.

Shooting Mode Parameters
Video Active HDR, Stabilization, Ratio, Duration, Resolution, Frame Rate
PureVideo Stabilization, Ratio, Duration, Resolution, Frame Rate
FreeFrame Video Active HDR, Ratio, Duration, Resolution, Frame Rate
TimeShift Stabilization, Ratio, Duration
Timelapse Resolution, Frame Rate, Stabilization, Ratio, Interval, Shoot length
Dashcam Active HDR, Loop Space, Time Watermark, Stabilization, Ratio, Resolution, Frame Rate
Loop Recording Active HDR, Stabilization, Ratio, Loop Duration, Resolution, Frame Rate
Slow Motion Stabilization, Ratio, Duration, Resolution, Frame Rate
Starlapse Type, Ratio, Duration, Resolution, Timer
Burst Photo Burst, Cache, Format, Ratio, Resolution, Timer
Interval Interval, Format, Ratio, Duration, Resolution, Timer
Photo Format, Ratio, Resolution, Timer

Shooting Parameter Settings

Swipe left from the right edge of the touchscreen to see the shooting parameter settings.
image Insta360

Parameters Description
Shutter Speed The time it takes for light to enter the camera. The faster the shutter speed, the clearer the image.
Sensitivity (ISO) Reflects how sensitive the sensor is to light. A higher sensitivity means the camera can capture more light for a brighter image.
Exposure Compensation Value (EV) In Auto Mode, you can adjust the EV to help with overexposure or underexposure.
White Balance (WB) Removes unrealistic colors and tones so colors are accurately captured in the image. A higher white balance produces warmer tones and lower results in cooler tones.
Exposure Preset It is recommended to use Anti-Flicker for daily scenes for the best image brightness. For action scenes, Jitter Blur Reduction can improve stability, but the image may be darker.
Filter Add different color tones and effects.
Metering Mode Face Priority prioritizes the face for brightness. Matrix ensures accurate exposure of the whole image.
I-Log A professional color profile that captures more detail for more flexible color grading in post-production.
Sharpness Enhance the contrast at the edges of the image to make blurry videos appear sharper.



Shooting Mode Parameters Parameters
Auto
Manual
Video Filters, EV, Metering Mode, Sharpness, I-Log, Exposure Preset, WB Filters, Shutter, ISO, EV, Sharpness, I-Log, WB
PureVideo Filters, EV, Exposure Preset, WB, Metering Mode Filters, EV, Exposure Preset, WB, Metering ModeB
FreeFrame Video Filters, EV, Metering Mode, Exposure Preset, Sharpness, I-Log, WB Filters, Shutter, Sharpness, I-Log, ISO, EV, WB
TimeShift Filters, EV, WB, Sharpness Filters, Shutter, ISO, EV, WB, Sharpness
Timelapse Filters, EV, WB, Sharpness Filters, Shutter, ISO, EV, WB, Sharpness
Dashcam Filters, EV, Metering Mode, Exposure Preset, Sharpness, I-Log, WB Filters, Shutter, ISO, EV, WB, Sharpness, I-Log
Loop Recording Filters, EV, Metering Mode, Exposure Preset, WB, Sharpness, I-Log Filters, Shutter, ISO, EV, WB, Sharpness, I-Log
Slow Motion Filters, EV, WB, Sharpness Filters, Shutter, ISO, EV, WB, Sharpness
Starlapse WB, EV Shutter, ISO, EV, WB
Burst Photo Filters, EV, WB Filters, Shutter, ISO, EV, WB
Interval Filters, EV, WB Filters, Shutter, ISO, EV, WB
Photo Filters, EV, Metering Mode, WB Filters, Shutter, ISO, EV, WB

Album Page

Swipe right from the left of the touchscreen to enter the Album page. image
